Red Arrow 14 Way Consumer Unit Preloaded with RCDs & MCBs
The Red Arrow ZC14-17MC-8L consumer unit is a complete, pre-configured solution for modern electrical installations. Supplied with RCDs and MCBs already fitted, it reduces installation time while ensuring compliance with current wiring regulations.
Designed for reliability and ease of use, this 14-way unit provides effective circuit protection for residential and light commercial applications.
Available Option
| Product | Description | Dimensions |
| ZC14-17MC-8L | 14 Way Consumer Unit (Preloaded) | 240mm x 325mm x 108mm |
Key Features
-
Preloaded Configuration: Supplied with 2 x 100A main isolators, 2 x 100A Type A RCDs and 8 MCBs for faster installation.
-
18th Edition Compliant: Dual RCD board designed to meet current IET wiring regulations.
-
Enhanced Protection: Type A RCDs protect against AC and pulsating DC currents.
-
Surge Protection Ready: Compatible with optional SPD devices for additional safety.
-
Durable Steel Enclosure: Robust construction for long-term reliability.
-
Professional Finish: Hinged visor provides clean and secure cable access.
Ideal Applications
-
Residential Installations: Safe and efficient power distribution for homes.
-
Light Commercial: Suitable for offices, shops and small business premises.
-
New Builds: Preloaded design reduces install time on new projects.
-
Refurbishments: Upgrade existing consumer units to current standards.
-
Garages & Outbuildings: Reliable distribution for secondary circuits.
Specifications
-
Ways: 14 Way
-
Main Isolators: 2 x 100A
-
RCD Type: Type A
-
MCBs Included: 8
-
IP Rating: IP2XC
-
IK Rating: IK05
-
Material: Steel
-
Finish: White
-
Operating Temperature: -20°C to +50°C
-
Compliance: UKCA, CE
-
Warranty: 5 Years
Delivery Information
These products are shipped directly from our supplier to ensure fast delivery and competitive pricing. UK mainland delivery is typically 1–2 working days from order confirmation.
