Red Arrow Zenith Architectural LED Wallpack - 110 Degrees Angle, IP65, IK10

Experience modern design and exceptional illumination with the Red Arrow Zenith Architectural Wallpack (ZENA), a versatile and stylish solution for enhancing any outdoor space.

It comes in different versions you can choose from depending on your needs.

Product Code Description Wattage Lumen Output Emergency
Lumen Output
Efficacy
ZENA-CCT Zenith 13W
18W
28W
1700 lm
2500 lm
3500 lm
- 131 lm/W
139 lm/W
125 lm/W
ZENAE-CCT Zenith c/w 3Hr Emergency 13W
18W
28W
1700 lm
2500 lm
3500 lm
275 lm 131 lm/W
139 lm/W
125 lm/W
ZENAPC-CCT Zenith c/w Photocell 13W
18W
28W
1700 lm
2500 lm
3500 lm
- 131 lm/W
139 lm/W
125 lm/W
ZENAEPC-CCT Zenith c/w 3Hr Emergency and Photocell 13W
18W
28W
1700 lm
2500 lm
3500 lm
275 lm 131 lm/W
139 lm/W
125 lm/W



Key Features:

  • Attractive Architectural Design: Enhance the aesthetics of your building exterior with the Zenith's sleek and contemporary design.
  • Selectable Lumen Output and Colour Temperature: Choose the perfect combination of brightness and warmth with selectable options for both lumen output and colour temperature (3000K/4000K) to suit any project.
  • Durable and Tamper-Resistant: Ensure long-lasting performance and security with the robust die-cast aluminium housing and tamper-resistant screws to the lens.
  • Efficient LED Technology: Experience exceptional brightness and energy savings with high lumen efficacy up to 139 lm/W.
  • Even Illumination with Wide Beam Angle: Achieve consistent and uniform light distribution with the 110 degree area flood beam angle.
  • Long-Lasting LED Lifetime: Benefit from a long lifespan of over 54,000 hours, minimizing maintenance requirements.
  • Integral Photocell Option: Automate operation and enhance energy savings with the optional built-in photocell for dusk-to-dawn illumination.
  • Emergency Option Available: Ensure safety during power outages with the available emergency backup option, providing 3 hours of illumination.
  • Robust Construction: Withstand harsh weather conditions and impact with the IP65-rated dust and water ingress protection and IK10-rated impact resistance.

Ideal Application:

  • Building Facades: Enhance the architectural appeal of your building with stylish and efficient lighting.
  • Signage and Artwork: Highlight signage and artwork with focused and vibrant illumination.
  • Walkways and Entrances: Create a safe and welcoming environment for pedestrians with reliable lighting.
  • Public Spaces: Improve visibility and security in parks, squares, and other outdoor areas.

Specification:

  • Material: Body: Die-Cast Aluminium
  • Diffuser: Polycarbonate
  • Colour Temperature: 3000K/4000K Selectable
  • Colour Finish: RAL7016 Anthracite
  • CRI: Ra>80
  • Beam Angle: 110 Degree Area Flood
  • LED Lifetime: L80B50 >54,000 Hrs
  • IP Rating: IP65
  • IK Rating: IK10
  • Working Temperature: -20 Celsius to 40 Celsius
  • Power Factor: >0.9
  • Emergency Battery Type: LifePO4
  • Electrical Class: Class I
  • Guarantee: 5 Years (Emergency batteries 2 years)
